Product Details
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: SKL
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: negotiable
Packaging Details: Std export term
Delivery Time: 5~7 days after payment
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 pcs / week
Applicable: |
ACSR 300~400 |
Model: |
SKL40 |
Rated Load: |
40 KN |
Max Gap: |
32 Mm |
Using: |
Tightening Conductor |
Name: |
Come Along Clamp |
Applicable: |
ACSR 300~400 |
Model: |
SKL40 |
Rated Load: |
40 KN |
Max Gap: |
32 Mm |
Using: |
Tightening Conductor |
Name: |
Come Along Clamp |
300-400 Sqmm Automatic Aluminum Alloy Come Along Clamp For ACSR AAAC Conductor
Conductor Gripper Description
Automatic aluminum alloy come along clamp for ACSR AAAC conductor is suitable to tighten the Insulated conductors or adjust of sag.With high stength aluminum titanium alloy forging, the weight is light.The jaw part adopts a special texture processing so that it can firmly clamp the cable and does not hurt the inner core whether winter or summer.
This wire rope gripper is widely used in adjusting of wire pulling such as electrical installation, it is made by high quality AL alloy, wire grips are using for Adjust tightening conductors in line construction.To meet the different demands, we have the rated load from 7KN to 80KN, applicable conductor ACSR 25mm2 to 1200mm2, Max open can reach 48mm. Also we have the other come along clamps, grippers, like self gripping clamps, flexible gripping clamps, and insulated conductor gripper.To support the Optical fibe cable stringing operation, there are some special grippers as usual,Radial loacking grip.
Conductor Wire Grip Specification
| Item No. | Model No. | Rated Load (KN) |
Applicable Conductor (ACSR-MM2) |
Max Open (MM) |
Unit Weight (KG) |
| 0201 | SKL-7 | 7 | 25~70 | 14 | 1.0 |
| 0202 | SKL-15 | 15 | 95~120 | 18 | 1.4 |
| 0203 | SKL-25 | 25 | 150~240 | 24 | 3.0 |
| 0204 | SKL-40 | 40 | 300~400 | 32 | 4.0 |
| 0205 | SKL-50 | 50 | 500~630 | 36 | 6.6 |
| 0206 | SKL-40G | 40 | 400 | 32 | 4.3 |
| 0207 | SKL-50G | 50 | 500 | 34 | 7.0 |
| 0208 | SKL-50GA | 50 | 630 | 36 | 7.3 |
| 0209 | SKL-60G | 60 | 720 | 38 | 9.2 |
| 0210 | SKL-70G | 70 | 900 | 42 | 14.0 |
| 0211 | SKL-80G | 80 | 1000 | 45 | 18.0 |
| 0212 | SKL-80GA | 80 | 1200 | 48 | 18.0 |
Features: Automatic Aluminum Alloy Come Along Clamp,It is made of high strength aluminous alloy with characteristics of compact and light.
Come Along Clamp:
Our Service:
| 1 | Well trained sales team service for you. |
| 2 | Small MOQ, usually sample is available. |
| 3 | Support OEM & ODM: we can print logo or customs package according to our client’s requirement. |
| 4 | Top quality: we have professional QC team to control the quality. |
| 5 | Timely delivery: we can send goods within 10~40 days after payment, it depend on products and quantity. |
| 6 | We work with DHL, UPS, FedEx, TNT and EMS for small order. For large order we can arrange shipment by air or by sea. |
| 7 | Satisfactory service: we treat clients as friends and 24 hours customer service. |
