Product Details
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: SHD
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Std export term
Delivery Time: 15-20 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 pcs / month
Item: |
Pulling Pulley Block |
Middle: |
Cast Steel Sheave |
Rated Load: |
40kn |
Weight: |
18kg |
Size: |
Sheave Dimension Customized |
Made: |
Ningbo China |
Conductor: |
ACSR400 |
Item: |
Pulling Pulley Block |
Middle: |
Cast Steel Sheave |
Rated Load: |
40kn |
Weight: |
18kg |
Size: |
Sheave Dimension Customized |
Made: |
Ningbo China |
Conductor: |
ACSR400 |
Cast Steel Sheave Middle 508mm Three Wheels Stringing Block For Conductor
Conductor stringing pulley block is applied for buiding on stilts to stretch to put conducting line in the power transmission wire ways is more available than an single split conducting line,double split conducting line,four split conducting line,six split conducting line etc.
Stringing pulley blocks;pulleys
Cast Steel Sheave Middle 508mm Three Wheels Stringing Block For Conductor
1) Outside Dia 508 mm;
2) Sheave: MC Nylon;
3) Frame: Galvanized steel;
4) Sheave number:1/3/5
Technical Parameters:Cast Steel Sheave Middle 508mm Three Wheels Stringing Block For Conductor
| Item Number | Model | Number of Sheave | Rated Load (kN) | Weight (kg) | Features of Sheave |
| 10101 | SHD508 | 1 | 20 | 18 | Rubber coated aluminum sheave |
| 10102 | SHS508 | 3 | 40 | 61 |
Middle: cast steel sheave Conductor: Rubber coated aluminum sheave |
| 10103 | SHW508 | 5 | 60 | 93 | |
| 10104 | SHDN508 | 1 | 20 | 16 | MC nylon sheave |
| 10105 | SHSLN508 | 3 | 40 | 47 |
Middle: MC nylon sheave Conductor: Rubber coated aluminum wheel |
| 10106 | SHWLN508 | 5 | 60 | 79 | |
| 10107 | SHSQN508 | 3 | 40 | 43 | MC nylon sheave |
| 10108 | SHWQN508 | 5 | 60 | 70 |
Note:Cast Steel Sheave Middle 508mm Three Wheels Stringing Block For Conductor
Galvanzied frame
Maximum suitable conductor ACSR400;
Sheave dimension ( outside diameter x root diamter xsheave width)
Sheave dimension Φ508×Φ408×75 (mm) can be customized.
