Product Details
Place of Origin: NINGBO CHINA
Brand Name: Lingkai
Certification: ISO
Model Number: LJ-300B LJ-500A LJ-500 SJZ-10B SJZ-10C
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: wooden case
Delivery Time: 5~15
Payment Terms: TT,LC
Supply Ability: 1000 sets/month
Features: |
High Strength, Durable, Reliable |
Packaging: |
Wooden Case |
Product Name: |
Wire Take Up Machine |
Material: |
8# Steel |
Warranty: |
1 Year |
Testing: |
Before Shipping |
Service: |
24/7 Technical Support |
Design: |
Drum Size Customized |
Features: |
High Strength, Durable, Reliable |
Packaging: |
Wooden Case |
Product Name: |
Wire Take Up Machine |
Material: |
8# Steel |
Warranty: |
1 Year |
Testing: |
Before Shipping |
Service: |
24/7 Technical Support |
Design: |
Drum Size Customized |
The Large Drum Cable Traction Winch is a specially designed and produced machinery that caters to the needs of the line construction. This device is mainly used for retrieving overhead ground wires or old wires on the line. The significant advantage of this machinery is that it completely replaces manual labor, thus reducing labor intensity and improving work efficiency. The power sector and construction units highly welcome its impressive features.
The Large Drum Cable Traction Winch comes with the added advantages of small size, high power, and flexible operation, making it an ideal companion for line construction. The machinery is easy to handle during operations, making it simpler and convenient for line construction teams. As a result of its usefulness, the machinery is highly in demand.
Item No. | 08151 | 08152 | |
Model | SJZ-10B | SJZ-10C | |
Engine | Model | GX160 Gasoline engine | Z170F Diesel engine |
Power (hp) | 5.5 | 4 | |
Speed (rpm) | 1500 | 2600 | |
Max. take-up force (KN) | 10 | 10 | |
Max. Take-up speed (m/min) | 41 | 41 | |
Reel Capacity (m) | ACSR95mm² | 600 | 600 |
ACSR120mm² | 460 | 460 | |
ACSR185mm² | 320 | 320 | |
Weight (kg) | 150 | 165 | |
Dimension (m) | 1.2 x 0.9 x 1 | 1.2 x 0.9 x 1 | |
Item No. | 08192 | 08193 | 08194 | |
Model | LJ-300B | LJ-500A | LJ-500 | |
Diameter of Capstans (mm) | Φ300 | Φ500 | Φ500 | |
Petrol Engine | Model | Petrol GX270 | R175A | Petrol GX270 |
Power (hp) | 9 | 6 | 9 | |
Speed (rpm) | 3600 | 2600 | 3600 | |
Pull force (KN) / Pull speed (m/min) | I | 25/8.5 | 16/10.5 | 16/13.6 |
II | 15/13.4 | 10/16.6 | 10/21.5 | |
III | 6/33.5 | 4/40.8 | 4/53.6 | |
Reverse | /9.6 | /11.8 | /15.3 | |
Dimension (mm) | 870 x 620 x 650 | 920 x 700 x 710 | 900 x 700 x 710 | |
Weight (kg) | 140 | 190 | 150 | |
The Large Drum Cable Traction Winch is a powerful machine designed specifically for the purpose of withdrawing old conductors or erecting overhead earth wires. Its main function is to pull cables along the ground or from a height, making it easier to install or remove them at the required location.
The Large Drum Cable Traction Winch can be powered by gasoline or diesel, providing flexibility in its use. This makes it ideal for use in remote locations where electricity may not be readily available. The machine is designed to be reliable and efficient, making it a popular choice among operators.
The Large Drum Cable Traction Winch adopts a big drum to store the cable, making it convenient for cable recycling. The large drum means that more cable can be stored on the machine, reducing the need for frequent refilling. This also allows for the machine to be used for longer periods of time without interruption.
The Tapered Drum Recovery Take-up Pulling Winch is an ideal solution for traction and lifting needs especially in mountainous and outdoor construction areas where there is no power supply available. This versatile machine has been designed with small size and light weight in mind, making it easy to transport and maneuver on site.
One of the standout features of the winch is its strong traction capability, which is achieved through the use of a specially designed tapered drum. This design enables the winch to maintain a consistent pulling force throughout each layer of cable wrapped around the drum. This feature is particularly important in harsh conditions where a steady and reliable pulling force is required.
The winch is also easy to operate and maintain, making it a popular choice for those who need to get the job done quickly and efficiently. The machine is comprised of several key parts including an engine, clutch, gearbox (with brake), cable reel, and other components (see attached diagram). Maintenance and repair is a breeze with this product, which means that you can keep your winch in optimal condition and ready to use at all times.
The Take-up Pulling Winch is a highly efficient device that is used in the withdrawal of old conductors or the erection of overhead earth wires. It is a versatile tool that can be used in cable recycling and is widely known for its convenience and ease of use.
This winch is designed to handle heavy-duty tasks and is a valuable asset for any contractor involved in the installation of electrical wiring systems. Its durable construction makes it suitable for use in various weather conditions and terrain types. The winch can be easily operated by a single person, making it an ideal option for those with limited manpower.
The Take-up Pulling Winch is a must-have device for any electrical contractor or utility company . It guarantees the safe and efficient completion of tasks while saving time and money. Whether you are erecting overhead earth wires or recycling cables, this winch is an indispensable tool that can help you achieve your goals with ease.
The Transmission Line Stringing Tools product comes with comprehensive technical support and services, which include:
Our team of experts is dedicated to providing the highest level of support and service to ensure that your Transmission Line Stringing Tools operate efficiently and effectively.
