Product Details
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: SHD660
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: Std export way
Delivery Time: 15-20 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000pcs/month
Features: |
Cast Sheave Middle |
Model: |
SHD660 |
Rated Load: |
40kn |
Materail: |
Nylon Sheave, Or Aluminum |
Number Of Sheave: |
2 |
Weight: |
30kg |
Features: |
Cast Sheave Middle |
Model: |
SHD660 |
Rated Load: |
40kn |
Materail: |
Nylon Sheave, Or Aluminum |
Number Of Sheave: |
2 |
Weight: |
30kg |
Single Sheave 660 Diameter Transmission Line Stringing Tools Stringing Block
Our 660 large diameter stringing block is fitted with the maximm suitable conductor LGJ550, this is to say the aluminum of this conducting wire possesses the cross section at most is 550 squre millimeters.
In addition, Block dimension (outside diameter *root diameter*sheave width)Φ660*Φ560*100mm.
the middle sheave of both 10122 and 10123 types has a width of 90mm, we can also supply the middle nylon sheave with the wide of 90mm for option, also the diamnsion of Φ660*Φ560*100mm can be customized.
Specifications
Single Sheave 660 Diameter Transmission Line Stringing Tools Stringing Block,it has one, three, five and seven sheaves.If only one sheave, it can be rubber coated aluminum sheave, and MC nylon sheave. Three, Five,Seven sheaves,has the Middle: cast steel sheave with the width of 90mm Conductor: rubber coated aluminum sheave.
| Item Number | Model | Number of Sheave | Rated Load (kN) | Weight (kg) | Features |
| 10121 | SHD660 | 1 | 20 | 30 | Rubber coated aluminum sheave |
| 10122 | SHS660 | 3 | 40 | 106 | Middle: cast steel sheave with the width of 90mm Conductor: rubber coated aluminum sheave |
| 10123 | SHW660 | 5 | 60 | 150 | |
| 10124 | SHDN660 | 1 | 20 | 24 | MC nylon sheave |
| 10125 | SHSLN660 | 3 | 40 | 92 | Middle: MC nylon sheave Conductor: rubber coated aluminum sheave |
| 10126 | SHWLN660 | 5 | 60 | 120 | |
| 10127 | SHSQN660 | 3 | 40 | 76 | MC nylon sheave |
| 10128 | SHWQN660 | 5 | 60 | 110 | |
| 10129 | SHQZ660 | 7 | 80 | 268 | Middle: cast steel sheave Conductor: rubber coated aluminum sheave |
| 10130 | SHQ660A | 7 | 75 | 190 | Middle: cast steel sheave Conductor: MC nylon sheave |
