Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: JJC 3,5 ,8
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Speed: |
Fast |
Gear: |
Four Gear |
Trademark: |
NBLK |
Package Gross Weight: |
140.000kg |
Rated Power: |
3 KW 4.5 KW. 8 KW |
Tractive Force: |
3 ,5 ,8Ton |
Dimension: |
1000*750*60mm |
Drum Feature: |
Detachable |
Speed: |
Fast |
Gear: |
Four Gear |
Trademark: |
NBLK |
Package Gross Weight: |
140.000kg |
Rated Power: |
3 KW 4.5 KW. 8 KW |
Tractive Force: |
3 ,5 ,8Ton |
Dimension: |
1000*750*60mm |
Drum Feature: |
Detachable |
A powered diesel winch is a robust mechanical device designed for heavy-duty pulling and lifting operations. It is driven by a diesel engine, making it versatile and suitable for various industrial applications.
The diesel winch comes in two types: belt driven and shaft driven. Both types are suitable for the construction of the tower line, traction line, tight line operation, and laying cables.
The belt driven winch is mainly used for laying cables in underground applications. It has four gear boxes for efficient operation.
The shaft driven winch is designed for overhead applications. It has six gear boxes, which makes it faster than the belt driven type. However, it is also more expensive.
Fast powered shaft driven winch data sheet.
| Item number | Model |
Rotation direction |
Gear |
Tractive force (T) |
Traction speed (M/MIN) |
Power (KW) |
Outline size (MM) |
Weight (KG) |
| 09131 |
JJQ-30 6HP Gasoline engine |
corotation | SlowⅠ | 3.0 | 5 | 4.04 | 900x400x430 | 94 |
| SlowⅡ | 2.0 | 7 | ||||||
| FastⅠ | 0.9 | 16 | ||||||
| FastⅡ | 0.6 | 24 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 13 | |||||||
| 09131A |
JJC-3 5HP Diesel engine |
corotation | SlowⅠ | 3.0 | 5 | 2.90 | 1000x450x500 | 115 |
| SlowⅡ | 2.0 | 7 | ||||||
| FastⅠ | 0.9 | 16 | ||||||
| FastⅡ | 0.6 | 24 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 13 | |||||||
| 09135 |
JJQ-5B 9HP Gasoline engine |
corotation | FastⅠ | 0.9 | 24 | 6.6 | 1100x525x600 | 138 |
| FastⅡ | 1.5 | 13 | ||||||
| SlowⅠ | 2.5 | 8 | ||||||
| SlowⅡ | 5.0 | 4 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 18 | |||||||
| 09135A |
JJC-5B 186F Diesel engine |
corotation | FastⅠ | 0.9 | 24 | 5.7 | 1000x498x600 | 148 |
| FastⅡ | 1.5 | 13 | ||||||
| lowⅠ | 2.5 | 8 | ||||||
| SlowⅡ | 5.0 | 4 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Slow | 18 |
Blet driven transmission line pulling winches
| Item number | Model |
Rotation direction |
Gear |
rotational speed () |
Traction speed (m/min) |
Tractive force (T) |
Power (KW) |
Outline size (mm) |
Weight (kg) |
| 09121 |
JJQ-3Q 6HP Gasoline engine |
corotation |
Ⅰ Slow |
9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
|
Ⅱ Fast |
16.0 | 6.6 | 1.8 | 780x450x500 | 85 | ||||
| reversal | Reverse | 7.5 | 3.3 | No lifting | |||||
| 09121A |
JJC-30 170F Diesel engine |
corotation |
Ⅰ Slow |
11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
|
Ⅱ Fast |
21.0 | 9.0 | 1.8 | ||||||
| reversal | Reverse | 10.0 | 4.5 | No lifting | |||||
| 09121B |
JJD-30 3KW Electromotor |
corotation |
Ⅰ Slow |
8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
|
Ⅱ Fast |
10.5 | 6.5 | 1.8 | ||||||
| reversal | Reverse | 7.0 | 3.0 | No lifting | |||||
| 09123 |
JJQ-50 9HP Gasoline engine |
corotation |
Ⅰ Slow |
6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
|
Ⅱ Fast |
16.0 | 9.0 | 2.2 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09123A |
JJC-50 6.6HP Diesel engine |
corotation |
Ⅰ Slow |
8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
|
Ⅱ Fast |
19.0 | 11.0 | 2.3 | ||||||
| reversal | Reverse | 10.0 | 5.5 | No lifting | |||||
| 09123B |
JJD-50 4KW Electromotor |
corotation |
Ⅰ Slow |
5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
|
Ⅱ Fast |
14.0 | 8.0 | 3.0 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09125 |
JJQ-80 13HP Gasoline engine |
corotation |
Ⅰ Slow |
5 | 3 | 8 | 9.60 | 1000x550x520 | 168 |
|
Ⅱ Fast |
9 | 5 | 4.5 | ||||||
| reversal | Reverse | 5 | 3 | No lifting | |||||
| 09125A |
JJC-80 10.5HP Diesel engine |
corotation |
Ⅰ Slow |
7 | 4 | 8 | 7.86 |
1000x750x630 | 230 |
|
Ⅱ Fast |
13 | 7.5 | 4 | ||||||
| reversal | Reverse | 6.5 | 3.7 | No lifting |
Diesel winches are versatile and powerful machines that are commonly used in various industries. Some of the main applications of diesel winches are:
Diesel winches are preferred over other types of winches in these industries because of their high pulling capacity and durability. They are capable of handling heavy loads and rugged terrain with ease.
When selecting a diesel winch, there are several factors to consider. These include:
Although diesel winches have many advantages, they also require regular maintenance to ensure optimal performance. Additionally, the emissions and noise levels of diesel engines should also be taken into consideration, especially in environmentally sensitive areas. Finally, diesel winches are typically more expensive than electric winches, but they offer greater power and pulling capacity.
Other factors to consider when selecting a diesel winch include the pulling capacity, rope length, and environmental conditions of operation. These factors will vary depending on the specific application and requirements of the job.
The Cable Winch Puller is a powerful and reliable tool designed to handle heavy-duty pulling tasks with ease. To ensure optimal performance and longevity, we offer a range of technical support and services, including:
Our team of knowledgeable and experienced technicians is dedicated to providing exceptional support and services to help you get the most out of your Cable Winch Puller. Contact us today to learn more.
