Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: 12-A 12-B
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Traction Speed(m/min): |
11.7 18.9 34.4 55.6 |
Traction Force(KN): |
60 37 20 12 |
Speed (RPM): |
2000 |
Travel Speed(Km/H): |
3-13 |
Wheel-base (mm): |
1040 |
Gear: |
Four Gear |
Outline Size(mm): |
2670x1040x1300 |
Trademark: |
NBLK |
Traction Speed(m/min): |
11.7 18.9 34.4 55.6 |
Traction Force(KN): |
60 37 20 12 |
Speed (RPM): |
2000 |
Travel Speed(Km/H): |
3-13 |
Wheel-base (mm): |
1040 |
Gear: |
Four Gear |
Outline Size(mm): |
2670x1040x1300 |
Trademark: |
NBLK |
This tractor is designed to be fast and efficient in pulling and lifting during tower erection. It is applicable for use with no-twist wire rope, making it an ideal choice for a wide range of applications.
This tractor is equipped with four gears, including two forward gears and two reverse gears. This provides excellent control and precision in operation, making it easy to use for both beginners and experienced operators.
The tractor features a double drum design with seven grooves, which protects the wire rope while also ensuring speedy and convenient operation. This makes it a great choice for even the most demanding lifting and pulling applications.
The grinding of the walking tractor has been reformed from the 12-type walking tractor, providing a level of reliability and durability that is hard to match. This means that you can rely on this tractor for even the most demanding tasks, knowing that it will deliver top performance every time.
| Item number | Model |
Ground Clearance(mm) |
Wheel-base (mm) |
Power (HP) |
Speed (RPM) |
Travel speed(Km/H) |
Outline size(mm) |
Weight(kg) |
| 09171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 550 |
| 09172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 600 |
| Gear | Ⅰ | Ⅱ | Ⅲ | IV | reversalⅠ | reversalⅡ |
| Traction force(KN) | 60 | 37 | 20 | 12 | / | / |
| Traction speed(m/min) | 11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
This walking winch is a modified version of a hand-supported tractor. The gearbox has been redesigned, and a three-level gear deceleration and gravity brake mechanism have been added to the box. The half-axis has been extended on the left and right of the front gearbox to drive the tire for movement. The grinding cylinder shaft has been extended to drive the grinding cylinder for twisted operation.
Despite its modifications, this machine still retains the qualities of the hand-supported tractor's structure. It is light to manipulate, flexible, and has excellent driving performance. It is also suitable for various operations, such as transmission line construction tower, launch, tightening, traction, lifting, and transportation.
The walking tractor winch is a highly versatile tool that has been restructured from the model 12 hand tractor to offer a more efficient and reliable method for pylon-conductor setting in power line construction.
Featuring a simple structure and easy operation, this winch is widely utilized due to its practicality and effectiveness in the field. It helps professionals to simplify their tasks and accomplish them more efficiently than ever before.
Whether you are a seasoned construction professional or an aspiring novice, the walking tractor winch is a must-have tool that will help you improve your productivity and streamline your work.
Invest in this reliable and powerful tool today and take your power line construction work to new heights of efficiency and productivity!
We also offer a range of services to help you get the most out of your Cable Winch Puller, including installation, maintenance, and repair. Our team of experienced technicians can provide on-site support to ensure that your equipment is up and running quickly and efficiently.
Additionally, we offer training and educational resources to help you and your team operate the Cable Winch Puller safely and effectively. Our goal is to provide you with the support and services you need to achieve maximum productivity and efficiency with your equipment.
Product Packaging:
- Cable Winch Puller
- User Manual
- Warranty Card
Shipping:
- We offer free shipping within the United States.
- International shipping is available with additional charges.
- Orders are typically processed and shipped within 1-2 business days.
- Shipping time varies depending on the destination and shipping method selected.
