Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: 12-A 12-B
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Travel Speed(Km/H): |
3-13 |
Package Gross Weight: |
880.000kg |
Traction Force(KN): |
60 37 20 12 |
Wheel-base (mm): |
1040 |
Ground Clearance(mm): |
150 |
Drum Feature: |
Detachable |
Trademark: |
NBLK |
Gear: |
Four Gear |
Travel Speed(Km/H): |
3-13 |
Package Gross Weight: |
880.000kg |
Traction Force(KN): |
60 37 20 12 |
Wheel-base (mm): |
1040 |
Ground Clearance(mm): |
150 |
Drum Feature: |
Detachable |
Trademark: |
NBLK |
Gear: |
Four Gear |
The Fast Speed Double Drum/Single Drum Winch Tractor is a versatile apparatus that can be used for pulling and lifting during tower erection. This machine is specifically designed to pull no-twist wire rope, making it a valuable asset for a variety of applications.
The winch tractor comes equipped with four gears, including forward and reverse, allowing the operator to adjust the speed to the job at hand. The double drum features seven grooves to protect the wire rope and make operations speedy and convenient. With this configuration, the winch tractor is a reliable and efficient tool for heavy lifting and pulling.
The grinding of the walking tractor has been reformed from the 12-type walking tractor in order to increase the efficiency and power of the winch tractor. This reform allows the winch tractor to operate at high speeds and with greater precision, making it an ideal choice for tower erection and other demanding projects.
| Item number | Model |
Ground Clearance(mm) |
Wheel-base (mm) |
Power (HP) |
Speed (RPM) |
Travel speed(Km/H) |
Outline size(mm) |
Weight(kg) |
| 09171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 550 |
| 09172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 600 |
| Gear | Ⅰ | Ⅱ | Ⅲ | IV | reversalⅠ | reversalⅡ |
| Traction force(KN) | 60 | 37 | 20 | 12 | / | / |
| Traction speed(m/min) | 11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
This walking winch is a modified version of a hand-supported tractor. The gearboxes have been redesigned, and a three-level gear deceleration and gravity brake mechanism were added to the box. On the front of the gearbox, a half-axis extends to the left and right to drive the tire. Moreover, the grinding cylinder shaft has been extended to drive the grinding cylinder for twisted operation.
Notably, this machine retains the characteristics of the hand-supported tractor's structure, making it light to manipulate, flexible and with good driving performance. This walking winch is not just limited to those features; it's also suitable for transmission line construction such as launch, tightening, traction, lifting, and transportation.
This walking winch is truly versatile. Its new gear system provides a smooth ride by reducing acceleration in three stages while the gravity brake provides additional security in case of accidents. As a result, this machine is perfect for all kinds of work environments – from flat terrain to steep slopes.
The inclusion of the grinding cylinder shaft in the gear system adds a unique feature to the walking winch. It can precisely operate at maximum efficiency while ensuring all tasks are executed with utmost care and precision.
The walking tractor winch is a modified version of the model 12 hand tractor. It has a simple structure which makes it easy to operate. This tool is widely used in the power line construction industry for pylon-conductor setting.
