Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: 12-A 12-B
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Trademark: |
NBLK |
Transport Package: |
WOODEN CASE |
Traction Speed(m/min): |
11.7 18.9 34.4 55.6 |
Speed (RPM): |
2000 |
Package Gross Weight: |
880.000kg |
Traction Force(KN): |
50 37 20 12 |
Wheel-base (mm): |
1040 |
Outline Size(mm): |
2670x1040x1300 |
Trademark: |
NBLK |
Transport Package: |
WOODEN CASE |
Traction Speed(m/min): |
11.7 18.9 34.4 55.6 |
Speed (RPM): |
2000 |
Package Gross Weight: |
880.000kg |
Traction Force(KN): |
50 37 20 12 |
Wheel-base (mm): |
1040 |
Outline Size(mm): |
2670x1040x1300 |
The Fast Speed Double Drum/Single drum Winch Tractor is a powerful tool designed for pulling and lifting during tower erection. It is capable of pulling no-twist wire ropes, making it suitable for a range of applications.
The Winch Tractor comes with four gears, including forward and reverse gears, making it easy to operate. The double drum design includes seven grooves, which effectively protect the wire rope, ensuring it stays secure and doesn't get tangled.
Additionally, the Winch Tractor is designed with speed and convenience in mind. It can operate at fast speeds, making it easy to get the job done quickly and efficiently. The walking tractor has been reformed from the 12 type walking tractor, giving it a sturdy and reliable design.
| Item number | Model |
Ground Clearance(mm) |
Wheel-base (mm) |
Power (HP) |
Speed (RPM) |
Travel speed(Km/H) |
Outline size(mm) |
Weight(kg) |
| 09171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 550 |
| 09172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 600 |
| Gear | Ⅰ | Ⅱ | Ⅲ | IV | reversalⅠ | reversalⅡ |
| Traction force(KN) | 60 | 37 | 20 | 12 | / | / |
| Traction speed(m/min) | 11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
This walking winch has been transformed from a hand-supported tractor, with the gearbox being redesigned and a three-level gear deceleration and gravity brake mechanism added to the box. Additionally, a half-axis has been extended to the left and right of the front of the gearbox to drive the tire. The grinding cylinder shaft has also been extended to drive the grinding cylinder rotation for twisted operation.
Despite these significant changes, this machine still retains the characteristics of the original hand-supported tractor, including easy manipulation, flexibility, and good driving performance. Moreover, it is suitable for transmission line construction tower operations such as launching, tightening, traction, lifting, and transportation.
This walking tractor winch is a modification of the model 12 hand tractor. Its structure is simple and easy to operate which makes it widely popular in the power line construction industry for their pylon-conductor setting needs.
The design of the walking tractor winch is efficient as it is restructured from the model 12 hand tractor. The modifications have led to its excellent performance and it delivers the required results from the power line construction industry. With its simple structure, it has become easy to operate by the workers of this industry.
The walking tractor winch is in high demand in the power line construction industry due to its easy handling and simple structure. It is used extensively for pylon-conductor setting and is preferred over other options. With its modification from the model 12 hand tractor, it has proven to be a reliable and efficient piece of equipment for electrical line construction.
