Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: JJC 3,5 ,8
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Trademark: |
NBLK |
Force Pulling: |
3T 5T 8T |
Carrying Capacity: |
Special Weight Level |
Slowi: |
2t |
Gear: |
Four Gear |
Rated Loading Capacity: |
3,5,8 Ton |
Rotational Speed: |
12 RPM 8 RPM |
Standard: |
National Standards |
Trademark: |
NBLK |
Force Pulling: |
3T 5T 8T |
Carrying Capacity: |
Special Weight Level |
Slowi: |
2t |
Gear: |
Four Gear |
Rated Loading Capacity: |
3,5,8 Ton |
Rotational Speed: |
12 RPM 8 RPM |
Standard: |
National Standards |
A powered diesel winch is a durable mechanical device that is specifically designed for heavy-duty pulling and lifting tasks. This winch is operated using a diesel engine, making it versatile and suitable for various industrial applications. It's available in two categories: belt-driven type and shaft-driven type.
The belt-driven type is mainly used for laying cables underground. It is equipped with a four-gear box that ensures its smooth performance. Conversely, the shaft-driven type is ideal for overhead line operations, as it has six gears and is faster than the belt-driven type. However, it's more expensive.
Both types of winches are suitable for construction tasks that include tower line construction, traction line operations, tight line operations, and laying cables.
Fast powered shaft driven winch data sheet.
| Item number | Model |
Rotation direction |
Gear |
Tractive force (T) |
Traction speed (M/MIN) |
Power (KW) |
Outline size (MM) |
Weight (KG) |
| 09131 |
JJQ-30 6HP Gasoline engine |
corotation | SlowⅠ | 3.0 | 5 | 4.04 | 900x400x430 | 94 |
| SlowⅡ | 2.0 | 7 | ||||||
| FastⅠ | 0.9 | 16 | ||||||
| FastⅡ | 0.6 | 24 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 13 | |||||||
| 09131A |
JJC-3 5HP Diesel engine |
corotation | SlowⅠ | 3.0 | 5 | 2.90 | 1000x450x500 | 115 |
| SlowⅡ | 2.0 | 7 | ||||||
| FastⅠ | 0.9 | 16 | ||||||
| FastⅡ | 0.6 | 24 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 13 | |||||||
| 09135 |
JJQ-5B 9HP Gasoline engine |
corotation | FastⅠ | 0.9 | 24 | 6.6 | 1100x525x600 | 138 |
| FastⅡ | 1.5 | 13 | ||||||
| SlowⅠ | 2.5 | 8 | ||||||
| SlowⅡ | 5.0 | 4 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 18 | |||||||
| 09135A |
JJC-5B 186F Diesel engine |
corotation | FastⅠ | 0.9 | 24 | 5.7 | 1000x498x600 | 148 |
| FastⅡ | 1.5 | 13 | ||||||
| lowⅠ | 2.5 | 8 | ||||||
| SlowⅡ | 5.0 | 4 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Slow | 18 |
Belt driven transmission line pulling winches
| Item number | Model |
Rotation direction |
Gear |
rotational speed () |
Traction speed (m/min) |
Tractive force (T) |
Power (KW) |
Outline size (mm) |
Weight (kg) |
| 09121 |
JJQ-3Q 6HP Gasoline engine |
corotation |
Ⅰ Slow |
9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
|
Ⅱ Fast |
16.0 | 6.6 | 1.8 | 780x450x500 | 85 | ||||
| reversal | Reverse | 7.5 | 3.3 | No lifting | |||||
| 09121A |
JJC-30 170F Diesel engine |
corotation |
Ⅰ Slow |
11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
|
Ⅱ Fast |
21.0 | 9.0 | 1.8 | ||||||
| reversal | Reverse | 10.0 | 4.5 | No lifting | |||||
| 09121B |
JJD-30 3KW Electromotor |
corotation |
Ⅰ Slow |
8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
|
Ⅱ Fast |
10.5 | 6.5 | 1.8 | ||||||
| reversal | Reverse | 7.0 | 3.0 | No lifting | |||||
| 09123 |
JJQ-50 9HP Gasoline engine |
corotation |
Ⅰ Slow |
6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
|
Ⅱ Fast |
16.0 | 9.0 | 2.2 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09123A |
JJC-50 6.6HP Diesel engine |
corotation |
Ⅰ Slow |
8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
|
Ⅱ Fast |
19.0 | 11.0 | 2.3 | ||||||
| reversal | Reverse | 10.0 | 5.5 | No lifting | |||||
| 09123B |
JJD-50 4KW Electromotor |
corotation |
Ⅰ Slow |
5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
|
Ⅱ Fast |
14.0 | 8.0 | 3.0 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09125 |
JJQ-80 13HP Gasoline engine |
corotation |
Ⅰ Slow |
5 | 3 | 8 | 9.60 | 1000x550x520 | 168 |
|
Ⅱ Fast |
9 | 5 | 4.5 | ||||||
| reversal | Reverse | 5 | 3 | No lifting | |||||
| 09125A |
JJC-80 10.5HP Diesel engine |
corotation |
Ⅰ Slow |
7 | 4 | 8 | 7.86 |
1000x750x630 | 230 |
|
Ⅱ Fast |
13 | 7.5 | 4 | ||||||
| reversal | Reverse | 6.5 | 3.7 | No lifting |
Main Applications:
Powered diesel winches have a wide range of applications in various industries, and some of the most common uses include:
Considerations:
While powered diesel winches offer several benefits compared to other types of winches, there are also a few considerations to keep in mind:
When selecting a powered diesel winch, it's essential to consider factors like pulling capacity, rope length, and environmental conditions of operation.
