Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: JJC 3,5 ,8
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Force Pulling: |
3T 5T 8T |
Dimension: |
1000*750*60mm |
Trademark: |
NBLK |
Slowi: |
2t |
Tractive Force: |
3 ,5 ,8Ton |
Carrying Capacity: |
Special Weight Level |
Gear: |
Four Gear |
Rated Power: |
3 KW 4.5 KW. 8 KW |
Force Pulling: |
3T 5T 8T |
Dimension: |
1000*750*60mm |
Trademark: |
NBLK |
Slowi: |
2t |
Tractive Force: |
3 ,5 ,8Ton |
Carrying Capacity: |
Special Weight Level |
Gear: |
Four Gear |
Rated Power: |
3 KW 4.5 KW. 8 KW |
Are you looking for a sturdy machine that can lift and pull heavy loads? Look no further than a powered diesel winch!
Powered by a diesel engine, these winches are incredibly versatile and can be used for a variety of industrial applications. Whether you're constructing a tower line, laying cables, or performing tight line operations, a powered diesel winch is the perfect tool for the job.
There are two types of powered diesel winches available: the belt type and the shaft driven type. While both are suitable for heavy-duty work, they have different applications.
Fast powered shaft driven winch data sheet.
| Item number | Model |
Rotation direction |
Gear |
Tractive force (T) |
Traction speed (M/MIN) |
Power (KW) |
Outline size (MM) |
Weight (KG) |
| 09131 |
JJQ-30 6HP Gasoline engine |
corotation | SlowⅠ | 3.0 | 5 | 4.04 | 900x400x430 | 94 |
| SlowⅡ | 2.0 | 7 | ||||||
| FastⅠ | 0.9 | 16 | ||||||
| FastⅡ | 0.6 | 24 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 13 | |||||||
| 09131A |
JJC-3 5HP Diesel engine |
corotation | SlowⅠ | 3.0 | 5 | 2.90 | 1000x450x500 | 115 |
| SlowⅡ | 2.0 | 7 | ||||||
| FastⅠ | 0.9 | 16 | ||||||
| FastⅡ | 0.6 | 24 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 13 | |||||||
| 09135 |
JJQ-5B 9HP Gasoline engine |
corotation | FastⅠ | 0.9 | 24 | 6.6 | 1100x525x600 | 138 |
| FastⅡ | 1.5 | 13 | ||||||
| SlowⅠ | 2.5 | 8 | ||||||
| SlowⅡ | 5.0 | 4 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Fast | 18 | |||||||
| 09135A |
JJC-5B 186F Diesel engine |
corotation | FastⅠ | 0.9 | 24 | 5.7 | 1000x498x600 | 148 |
| FastⅡ | 1.5 | 13 | ||||||
| lowⅠ | 2.5 | 8 | ||||||
| SlowⅡ | 5.0 | 4 | ||||||
| reversal | Slow | No lifting | 4 | |||||
| Slow | 18 |
Belt driven transmission line pulling winches
| Item number | Model |
Rotation direction |
Gear |
rotational speed () |
Traction speed (m/min) |
Tractive force (T) |
Power (KW) |
Outline size (mm) |
Weight (kg) |
| 09121 |
JJQ-3Q 6HP Gasoline engine |
corotation |
Ⅰ Slow |
9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
|
Ⅱ Fast |
16.0 | 6.6 | 1.8 | 780x450x500 | 85 | ||||
| reversal | Reverse | 7.5 | 3.3 | No lifting | |||||
| 09121A |
JJC-30 170F Diesel engine |
corotation |
Ⅰ Slow |
11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
|
Ⅱ Fast |
21.0 | 9.0 | 1.8 | ||||||
| reversal | Reverse | 10.0 | 4.5 | No lifting | |||||
| 09121B |
JJD-30 3KW Electromotor |
corotation |
Ⅰ Slow |
8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
|
Ⅱ Fast |
10.5 | 6.5 | 1.8 | ||||||
| reversal | Reverse | 7.0 | 3.0 | No lifting | |||||
| 09123 |
JJQ-50 9HP Gasoline engine |
corotation |
Ⅰ Slow |
6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
|
Ⅱ Fast |
16.0 | 9.0 | 2.2 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09123A |
JJC-50 6.6HP Diesel engine |
corotation |
Ⅰ Slow |
8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
|
Ⅱ Fast |
19.0 | 11.0 | 2.3 | ||||||
| reversal | Reverse | 10.0 | 5.5 | No lifting | |||||
| 09123B |
JJD-50 4KW Electromotor |
corotation |
Ⅰ Slow |
5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
|
Ⅱ Fast |
14.0 | 8.0 | 3.0 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09125 |
JJQ-80 13HP Gasoline engine |
corotation |
Ⅰ Slow |
5 | 3 | 8 | 9.60 | 1000x550x520 | 168 |
|
Ⅱ Fast |
9 | 5 | 4.5 | ||||||
| reversal | Reverse | 5 | 3 | No lifting | |||||
| 09125A |
JJC-80 10.5HP Diesel engine |
corotation |
Ⅰ Slow |
7 | 4 | 8 | 7.86 |
1000x750x630 | 230 |
|
Ⅱ Fast |
13 | 7.5 | 4 | ||||||
| reversal | Reverse | 6.5 | 3.7 | No lifting |
A diesel winch has several applications, including construction, mining, forestry, marine operations, and the oil and gas industry.
While diesel winches have numerous benefits, they require regular maintenance to ensure their optimal performance. Moreover, they generate significant noise and emissions that may cause pollution and noise pollution. Electric winches may be a cheaper alternative to diesel winches in terms of their initial cost.
When selecting a powered diesel winch, it is crucial to consider several factors such as the winch's pulling capacity, rope length, and environmental conditions of operation. These factors play a critical role in the efficiency and effectiveness of the winch.
The Cable Winch Puller is a durable and reliable product designed to assist in heavy-duty pulling tasks. Our technical support team is available to assist with any questions or concerns related to the installation, operation, or maintenance of the product. We provide comprehensive product training to ensure that our customers are able to use the Cable Winch Puller safely and effectively. Additionally, we offer repair and replacement services for any damaged or malfunctioning parts. Our commitment to customer satisfaction means that we are dedicated to providing timely and efficient support and services to ensure that our customers are able to maximize the value of their investment in the Cable Winch Puller.
