Product Details
Place of Origin: NINGBO CHINA
Brand Name: NBLK
Certification: ISO
Model Number: JJCS50
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: GET THE LATEST
Packaging Details: WOODEN CASE
Delivery Time: 3-5DAYS
Payment Terms: T/T
Supply Ability: 200SETS/MONTH
Drum Bottom Of Groove Diameter: |
300mm |
Engine: |
S195G Diesel |
Power HP: |
9 |
Weight: |
700kgs |
Strength: |
5T |
Rmp Speed: |
2000 |
Function: |
Stringing Conductor Wires,laying Cables |
Drum Bottom Of Groove Diameter: |
300mm |
Engine: |
S195G Diesel |
Power HP: |
9 |
Weight: |
700kgs |
Strength: |
5T |
Rmp Speed: |
2000 |
Function: |
Stringing Conductor Wires,laying Cables |
For those operating and maintaining diesel engine powered winches, this manual is a critical resource. It provides all of the essential information needed for proper use and upkeep. Without following the instructions presented herein, optimal performance and correct functioning of the equipment cannot be guaranteed.
The importance of adhering to the instructions in the manual cannot be overstated. Failure to do so may result in damage to the winch or other properties, personal injury or loss of life. As a helpful tip, it is recommended to read the entire manual before using the winch and to refer back to it as necessary.
Lastly, please be aware that we are always making improvements to our products. Therefore, materials and specifications may change without notice or obligation. The manual will be updated as needed to reflect these changes.
The JJCS 50 Diesel Engine Double Drum Winch Trailer is a specialized equipment designed for heavy-duty lifting and towing applications. This equipment is perfect for those who need to work in tough environments and require durable handling of loads. Whether you are in construction, logging, or marine applications, this winch trailer can be a reliable partner in hauling heavy loads.
The double drum design of this winch trailer allows for simultaneous operation, which increases efficiency when pulling or lifting heavy loads. The diesel engine provides robust power and ensures reliable performance in demanding conditions. Being trailer mounted enhances mobility of the equipment, allowing for easy transport to different job sites. This winch trailer can handle significant weights, making it suitable for construction, logging, and marine applications. Lastly, this equipment is built with high-strength materials to withstand harsh environments and heavy usage, making it more durable.
| Item number | 09162B | 09154 | 09162 | |
| Model | JJCS-50J | JJQS-50J | JJCS-50T | |
| Engine | Model | KF186FA Diesel Engine | Honda 390 Gasoline Engine |
S195G Diesel Engine |
| Power(KW) | 6.3 | 6.6 | 9 | |
| Speed(rpm) | 2600 | 3600 | 2000 | |
|
Pull force(KN)/ speed (m/Min) |
Slow | 50/6 30/10 | 50/6 30/10 | 50/3.1,40/9.6 |
| Moderate | / | / | 45/7.1 17/22.3 | |
| Fast | 13/23 10/30 | 13/23 10/30 | 33/11.3 10/35.6 | |
| Reverse | -/5 -/17 | -/5 -/17 | -/7.35 | |
| Drum bottom of groove diamete(mm) | Φ230 | Φ230 | Φ300 | |
| Outline size (mm) | 1280x770x600 | 1280x770x600 | 2440x1300x1140 | |
| Weight(kg) | 280 | 270 | 700 | |
The double drum winch is a versatile tool that finds application in a variety of industries like power transmission and distribution engineering, tower erection, and electrical power line construction, to name a few. It is primarily used for traction cable, line, hoisting tools, tower erection, pole setting and stringing wire.
The winch is designed with a double drum structure to reduce the damage of the wire rope during traction. It is driven by a belt, which helps to prevent overload damage. The winch can be powered by either diesel or gasoline power as per requirements.
The jjcs-50t model of the double drum winch can generate up to six traction gears, and these different gears correspond to varying levels of traction force and speed. Furthermore, the winch is installed on a rack, which is mounted on a trailer to make transportation easier and more convenient.
The JJCS 50 Diesel Engine Double Drum Winch Trailer is versatile and can be used in a variety of construction and maintenance scenarios. Its design is tailored to meet the demands of different tasks and ensure efficient and safe operations. Some of the primary applications of this winch trailer include:
To sum up, the JJCS 50 Diesel Engine Double Drum Winch Trailer is a versatile equipment designed to support efficient and safe operations in different construction and maintenance scenarios.
The Conductor Stringing Tools product comes with comprehensive technical support and services to ensure that the product operates optimally and efficiently. Our team of experts is available to assist with any technical issues or questions that may arise during the installation, operation, and maintenance of the product.
We offer training and support services to our customers to ensure that they have a thorough understanding of the product and can operate it safely and effectively. Additionally, we provide regular maintenance services to keep the product in top condition and extend its lifespan.
Our technical support and services are designed to minimize downtime and maximize productivity, ensuring that our customers can complete their projects on time and within budget. Contact us for more information on our technical support and services for the Conductor Stringing Tools product.
