Product Details
Place of Origin: NINGBO CHINA
Brand Name: NBLK
Certification: ISO
Model Number: JJCS50
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: GET THE LATEST
Packaging Details: WOODEN CASE
Delivery Time: 3-5DAYS
Payment Terms: T/T
Supply Ability: 200SETS/MONTH
Function: |
Stringing Conductor Wires,laying Cables |
Drum Bottom Of Groove Diameter: |
300mm |
Rmp Speed: |
2000 |
Engine: |
S195G Diesel |
Strength: |
5T |
Power HP: |
9 |
Weight: |
700kgs |
Function: |
Stringing Conductor Wires,laying Cables |
Drum Bottom Of Groove Diameter: |
300mm |
Rmp Speed: |
2000 |
Engine: |
S195G Diesel |
Strength: |
5T |
Power HP: |
9 |
Weight: |
700kgs |
This manual provides all the essential information required for operating and maintaining the diesel engine powered winch.
In order to achieve optimal performance and ensure correct functioning of the machine, please ensure that you follow all the instructions provided in this manual.
It is important to note that our factory is committed to ensuring the highest quality products. As such, we are constantly improving our processes, and therefore materials and specifications may be subject to change without notice or obligation.
| Item number | 09162B | 09154 | 09162 | |
| Model | JJCS-50J | JJQS-50J | JJCS-50T | |
| Engine | Model | KF186FA Diesel Engine | Honda 390 Gasoline Engine |
S195G Diesel Engine |
| Power(KW) | 6.3 | 6.6 | 9 | |
| Speed(rpm) | 2600 | 3600 | 2000 | |
|
Pull force(KN)/ speed (m/Min) |
Slow | 50/6 30/10 | 50/6 30/10 | 50/3.1,40/9.6 |
| Moderate | / | / | 45/7.1 17/22.3 | |
| Fast | 13/23 10/30 | 13/23 10/30 | 33/11.3 10/35.6 | |
| Reverse | -/5 -/17 | -/5 -/17 | -/7.35 | |
| Drum bottom of groove diamete(mm) | Φ230 | Φ230 | Φ300 | |
| Outline size (mm) | 1280x770x600 | 1280x770x600 | 2440x1300x1140 | |
| Weight(kg) | 280 | 270 | 700 | |
The JJCS 50 Diesel Engine Double Drum Winch Trailer is a specialized piece of equipment that has been specifically designed to cater to heavy-duty lifting and towing applications with ease. It comes equipped with several advanced features and specifications that enhance its overall performance and reliability, making it a popular choice among professionals in various industries.
One of the key features of this high-quality machine is its Double Drum Design, which enables it to operate simultaneously and increase efficiency when lifting heavy objects or pulling loads. This feature alone saves time and energy, giving added value to the user.
Another important feature is its Diesel Engine, which provides robust power to handle even the most demanding applications, ensuring superior performance in a variety of environments. This advanced technology feature ensures that it can be used for sustained periods even in challenging climates.
The Trailer Mounted feature of this machine is another aspect that enhances its mobility, making it easy to transport to different job sites seamlessly. This means that the JJCS 50 Diesel Engine Double Drum Winch Trailer is ideal for professionals who require exceptional versatility and adaptability in their work.
Moreover, this machine has an incredibly High Load Capacity, allowing it to handle significant amounts of weight easily. Construction, logging, and marine applications are no problem for this machine, making it a favorite among professionals across multiple industries.
Durability is also a vital aspect of any heavy-duty machine, and the JJCS 50 Diesel Engine Double Drum Winch Trailer is built to handle even the most severe conditions with ease. The high-strength materials used in its construction make it robust and protect it from harsh environments and heavy usage, ensuring that the machine lasts longer and maintains its performance throughout its lifetime.
The Double Drum Winch is a versatile tool used in various applications, including power transmission, distribution engineering, telephone construction tower erection, traction cable, line, hoisting tools, tower erection, pole setting, and stringing wire in electrical power line construction.
The winch is driven by a belt, which effectively prevents the damage of overload, and the double drum structure can reduce the damage of the wire rope during traction. With its high power, the winch can be operated with either diesel or gasoline as per the requirement.
The JJCS-50T model of the Double Drum Winch has up to 6 traction gears, and different traction forces correspond to different traction speeds, thus making it an efficient and versatile tool for all construction needs. What's more, the rack is installed on the trailer to facilitate transportation, making it easily portable to any construction site.
Applications
The JJCS 50 Diesel Engine Double Drum Winch Trailer is a versatile piece of equipment that can assist in various construction and maintenance scenarios. Its primary uses include:
Whether it's lifting heavy equipment or pulling cables, this winch trailer is designed to provide efficient and safe operations. Its diesel engine and double drum winch system ensure strong pulling power, while its trailer design allows for easy transportation between job sites. With the JJCS 50, construction and maintenance teams can complete their tasks with confidence and ease.
Our Conductor Stringing Tools come with comprehensive technical support and services to ensure the smooth operation of the product. Our team of experts is available to answer any product-related queries and to provide technical assistance whenever required.
We also offer maintenance and repair services to ensure that the Conductor Stringing Tools continue to function optimally and efficiently. Our technicians are skilled and experienced in conducting repairs and maintenance on our products, and use only genuine parts to ensure maximum reliability and longevity.
In addition, we provide training and education services to ensure that our customers are equipped with the knowledge and skills required to operate the Conductor Stringing Tools proficiently and safely. Our training modules cover all aspects of the product, including safety procedures, best practices, and troubleshooting techniques.
