Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: 12-A 12-B
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Wheel-base (mm): |
1040 |
Trademark: |
NBLK |
Travel Speed(Km/H): |
3-13 |
Traction Speed(m/min): |
11.7 18.9 34.4 55.6 |
Ground Clearance(mm): |
150 |
Traction Force(KN): |
60 37 20 12 |
Package Gross Weight: |
880.000kg |
Outline Size(mm): |
2670x1040x1300 |
Wheel-base (mm): |
1040 |
Trademark: |
NBLK |
Travel Speed(Km/H): |
3-13 |
Traction Speed(m/min): |
11.7 18.9 34.4 55.6 |
Ground Clearance(mm): |
150 |
Traction Force(KN): |
60 37 20 12 |
Package Gross Weight: |
880.000kg |
Outline Size(mm): |
2670x1040x1300 |
The Fast Speed Double Drum/Single Drum Winch Tractor For Pulling and Lifting During Tower Erection is designed for pulling and lifting tasks and is specifically designed to handle no-twist wire ropes. This efficient machine is ideal for tower erection tasks, ensuring that work is completed safely and efficiently.
The winch tractor features four gears, including both forward and reverse gears. The double drum, seven groove design helps to protect the wire rope, making it a reliable and sturdy option for heavy-duty tasks. The winch tractor is designed for speed and convenience, helping to improve productivity and efficiency on job sites.
The machine's walking tractor is reformed from the 12 type walking tractor, ensuring that it is powerful and capable of handling tough terrain. The high-quality engineering and construction of the winch tractor ensures that it is durable and long-lasting, making it a valuable investment for any job site.
| Item number | Model |
Ground Clearance(mm) |
Wheel-base (mm) |
Power (HP) |
Speed (RPM) |
Travel speed(Km/H) |
Outline size(mm) |
Weight(kg) |
| 09171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 550 |
| 09172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 | 600 |
| Gear | Ⅰ | Ⅱ | Ⅲ | IV | reversalⅠ | reversalⅡ |
| Traction force(KN) | 50 | 37 | 20 | 12 | / | / |
| Traction speed(m/min) | 11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
A walking winch was transformed from a hand-supported tractor. The gearboxes were reworked to include a three-level gear slowdown and a gravity brake mechanism. The extension of the half-axis on the left and right of the gearbox's front drives the tire. Additionally, the grinding cylinder shaft is extended to rotate for twisted operation.
This machine still possesses the lightweight structure, flexibility and outstanding driving performance of a hand-supported tractor, while also fitting the requirements of operations that involve transmission line construction towers. These include launching, tightening, traction, lifting and transportation.
The walking tractor winch that we offer is a modified version of the model 12 hand tractor, designed to better suit the requirements of construction work. This machine is largely used in power line construction to set up pylons and conductors. It has a simple structure and is extremely easy to operate.
The walking tractor winch is redesigned from the model 12 hand tractor to better suit the requirements of power line construction. The modifications to this machine have resulted in a simple yet effective structure that is highly suitable for this type of construction work. It is equipped with a winch that performs the task of setting up pylons and conductors with ease.
One of the greatest benefits of the walking tractor winch is the fact that it is easy to operate. The machine is designed to be user-friendly and requires minimal training before it can be operated. The simple design makes it easy to handle on site and it can be operated by a single person, making it extremely efficient for power line construction work.
The walking tractor winch is a highly versatile machine that is widely used in power line construction. Its simple design and ease of use make it a popular choice for contractors working in this industry. It is perfect for setting up pylons and conductors and can be used in a variety of different locations. This machine is an essential tool for anyone involved in power line construction.
Our team of experienced technicians is available to answer any questions you may have about the product and its capabilities. We can assist you with installation and setup, troubleshooting, and maintenance to ensure that your Cable Winch Puller is always operating at peak performance.
In addition to our technical support services, we offer a range of training programs to help you and your team get the most out of your Cable Winch Puller. Our training programs cover topics such as safe operation, proper maintenance, and advanced techniques for using the product in specific applications.
At our company, we are committed to providing exceptional customer service and support for all of our products, including the Cable Winch Puller. Contact us today to learn more about our technical support and services.
