Product Details
Place of Origin: NINGBO CHINA
Brand Name: LINGKAI
Certification: ISO
Model Number: SX4-VI
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: get the latest
Packaging Details: exported packing
Delivery Time: 20days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 50 sets/month
Power Of Engine (KW): |
23.5 |
Diameter Of Wheel (mm): |
300 |
Max. Diameter Of Steel Rope (mm): |
16 |
Max. Speed (km/h): |
22 |
MODEL: |
SX4-VI |
WEIGHT: |
1450 KGS |
Power Of Engine (KW): |
23.5 |
Diameter Of Wheel (mm): |
300 |
Max. Diameter Of Steel Rope (mm): |
16 |
Max. Speed (km/h): |
22 |
MODEL: |
SX4-VI |
WEIGHT: |
1450 KGS |
The engine puller is designed and modified from BENYE324 four wheel drive tractor, the machine has excellent mobility on transmission line stringing site.
It is equipped with mechanical gear box and automatic brake system, easy for pulling conductor or OPGW on mountain area.
SX4-VI Tractor type Puller
Item No.: 08125
Model: SX4-VI
Technical Data:
| Gear Shifting | I | II | III | Reverse |
| Pull force (KN) | 40 | 30 | 20 | |
| Pull Speed (m/h) | 715 | 1275 | 2270 | 650 |
Features: It is designed and modified from BENYE324 four wheel drive tractor, the machine has excellent mobility on site. With mechanical transmission and dual brake system, the puller is easy to operate.
Dimension (m): 2.6 x 1.6 x 1.9
Weight (kg): 1450
