Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO
Model Number: JJCS
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Drum Size: |
230mm 300mm |
Capacity: |
30 Kn 50kn |
Warrenty: |
1 Year |
Power: |
9KW |
Gear Box: |
Six |
Engine: |
Diesel And Gasonline |
Drum Size: |
230mm 300mm |
Capacity: |
30 Kn 50kn |
Warrenty: |
1 Year |
Power: |
9KW |
Gear Box: |
Six |
Engine: |
Diesel And Gasonline |
Introducing the Three Tons Dual-Bull Wheel Winch, a machine that was designed and produced based on the needs of line construction. This machine is ideal for traction and lifting purposes in field construction. It is mainly used for erecting pylons, traction wire laying, stringing and other operations related to electricity, post and telecommunications lines.
Second Paragraph: FeaturesThe Three Tons Dual-Bull Wheel Winch is equipped with a double capstan structure that causes little to no damage to the wire rope, making it the perfect choice for power sectors and construction units in China and all across the world. The machine offers unmatched efficiency and is a great investment for those who require a high-quality traction and lifting machine.
Third Paragraph: BenefitsThe machine has several benefits that make it stand out among competitors. It is built for heavy-duty performance, allowing it to handle even the toughest of jobs with ease. Its wide range of applications makes it an essential tool in the line construction industry. Furthermore, the machine is easy to use and maintain, ensuring maximum uptime and reduced downtime.
Fourth Paragraph: ConclusionIn conclusion, the Three Tons Dual-Bull Wheel Winch brings unmatched performance, efficiency, and reliability to any job site. With its wide range of applications and benefits, it is an ideal choice for line construction purposes. This machine is the perfect investment for anyone who needs a top-of-the-line traction and lifting machine, and ensures that you get the job done efficiently and effectively.
TECHNICAL DATA
| Item number | 09162A | 09162B | 09162 | |
| Model | JJCS-50 | JJQS-50 | JJCS-50 | |
| Engine | Model | Diesel Engine | Gasoline Engine | Diesel Engine |
| Power(KW) | 9 | 9 | 9 | |
| Speed(rpm) | 2000 | 3600 | 2000 | |
|
Pull(KN) speed force/ (M/MIN) |
Slow | 50/5 | 50/5 | 50/3.1,40/9.6 |
| Moderate | 25/9 14/14 | 25/9 14/14 | 45/7.1,17/22.3 | |
| Fast | 8/22 | 8/22 | 33/11.3,10/35.6 | |
| Reverse | -/5 -/9 | -/5 -/9 | -/7.35 | |
| Drum bottom of groove diamete(MM) | Φ230 | Φ230 | Φ300 | |
Clutch & Hand Braking
The engine's power is transferred by the clutch to the outer cone-shaped block, which moves synchronously through the pulley (or elastic coupling device). The clutch has a middle position called the disengagement position.
Please note that the clutch contains two bearings, namely 6205-2Z and 51110. It is advisable to replace them every 1000 hours or based on the actual operation. Remember to fill them with lithium grease before assembling.
Gearbox
The gearbox has three main sections, namely shift, brake and deceleration. The shift section uses high precision carburizing gear to transform the power to three forward gears and one reverse gear. The power is then passed to the clutch shaft through the reduction gear. The overrunning clutch is used as the machine's brake, with automatic braking function.
Coupled with the clutch handle controlling the hand brake, the machine has two sets of brake devices to ensure construction safety. Finally, the deceleration section consists of a Three-stage reduction gear that has large transmission ratio, small size and light weight.
The Three Tons Dual–Bull Wheel Winch is an incredible and versatile piece of machinery that can be used without power in outside fields. This machine works as a traction and lifting machinery to fulfill the needs of mountains areas and outside fields.
The traction of this equipment is powerful, and the operation is simple and user-friendly. This machine is designed with a double capstan that reduces damage to the steel wire rope. It consists of various components such as an engine, clutch, gearbox with brake, reel, and many others.
The machine is straightforward to operate, easy to maintain, and repair, which has been highly appreciated by users. It is an ideal piece of equipment for those who are looking for efficient and reliable machinery to meet the demands of mountainous areas and outside fields.
The Tower Erection Tools product technical support and services include:
Our team of experts is dedicated to providing top-notch support and ensuring the optimal performance of your tower erection tools.
Product Packaging:
Shipping:
